CURT 51110 Venturer Electric Trailer Brake Controller, Time-Delay
The Venturer is a compact, easy-to-set-up time-based brake controller. It can be mounted at any angle and has an automatic power level adjustment feature. It can operate one to three axles at a time, meaning two to six brakes, and has an LED display for monitoring brake pressure. Venturer is compatible with anti-lock brakes, cruise control and comes with a limited lifetime warranty. This CURT trailer brake controller is designed to work with quick plugs so it can readily plug into your vehicle's original equipment socket. It also includes a mounting bracket and hardware for easy installation. A brake controller should be mounted somewhere on the dash of your vehicle, and we recommend putting it below the steering wheel, either on the right or left side of the steering column. This way the control will not block your view when driving, but it will remain accessible and visible when adjustment is needed.
- Incr. Brake Power Based On Gain Setting And Sensitivity Adj.
- Operates 2-6 Trailer Brakes At A Time (1-3 Axles)
- No Internal Moving Parts And No Leveling Required
- Led Indicator Lengthens As Controller Applies Power
- Mounts Anywhere In The Vehicle At Any Angle
- Features Adjustable Power And Ramp Time
- Compatible w/Anti-Lock Brakes And Cruise Control
- Equipped w/A Quick Plug For Fast Easy Installation
Information:
Venturer Time-Delay Trailer Brake Controller; Increases brake power based on gain setting and sensitivity adjustment; Operates 2-6 trailer brakes at a time (1-3 axles); No internal moving parts and no leveling required; LED indicator lengthens as controller applies power; Mounts anywhere in the vehicle, at any angle; Features adjustable power and ramp time; Compatible with low-volt, PWM, ABS, cruise control and electric over hydraulic; Plug-and-play install with vehicle-specific quick plug harness (sold separately); Limited lifetime warranty
Application Summary:
| Year |
Make/Model |
| CURT |
51110 Venturer Electric Trailer Brake Controller, Time-Delay |
| Attributes |
| ASIN |
B0033WDG58 |
| Activation |
Time-Based |
| Axles |
1-3 |
| Box Height in Inches - XA |
3 |
| Box Length in Inches - XA |
15 |
| Box Width in Inches - XA |
5 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Container Volume Cubic Feet - XA |
0.00000 |
| Container Volume Cubic Meter - XA |
0.00000 |
| Country of Origin (Primary) |
CN |
| Display |
LED |
| Emission Code |
Legal US |
| Finish - XA |
N/A |
| GTIN |
00612314511105 |
| Harmonized Tariff Code (Schedule B) |
8537109160 |
| Hazardous Material Code |
N |
| Item Class - XA |
CME |
| Item Height - XA |
0.000 |
| Item Length - XA |
0.000 |
| Item Width - XA |
0.000 |
| Level Adjust |
Auto |
| Life Cycle Status Code |
Discontinued |
| Long Description |
Venturer Brake Control |
| Master Case Height Inches - XA |
9.000 |
| Master Case Length Inches - XA |
12.000 |
| Master Case Qty - XA |
12 |
| Master Case Volume Cubic Feet - XA |
0.00000 |
| Master Case Weight Lbs - XA |
7.000 |
| Master Case Width Inches - XA |
10.000 |
| Material - XA |
Blank |
| Mount Angles |
Any |
| Mount Type Description - XA |
Blank |
| NAFTA Preference Criterion Code |
B |
| Pallet Case Per Layer - XA |
12 |
| Pallet Cases Per Layer - XA |
12 |
| Pallet Layer of Cases - XA |
4 |
| Pallet Total Height Inches - XA |
0.000 |
| Pallet Total Weight Per - XA |
0.000 |
| Parcel Allowed - XA |
Yes |
| Product Weight - XA |
0.000 |
| Rate Class - XA |
70.0 |
| Retail Height - XA |
2.000 |
| Retail Length - XA |
8.125 |
| Retail Width - XA |
4.625 |
| SDR Required Flag |
N |
| Sales Family Code - XA |
ELECT |
| Sales Family Description - XA |
ELECTRICAL COMPONENTS |
| Sales Group Description - XA |
CNTRL |
| Shipping Weight - XA |
0.500 |
| Side Application Type Description - XA |
Blank |
| Tariff 301 - XA |
Yes |
| Truckload Volume Cubic Feet - XA |
0.00000 |
| Warranty |
Limited Lifetime |
