Edelbrock Marine Series 600 cfm, Square-Flange, Electric Choke Carburetor (non-EGR)
The Edelbrock 1409 Marine Series 600 CFM electric choke carburetor is a precisely tuned, quality-built carburetor that can handle the harsh abuse only a marine environment can inflict. Several characteristics make the 1409 Marine Series 600 CFM electric choke carburetor an outstanding marine performer. The first one is that metering rods are utilized to transition between circuits. The carburetor is unaffected by engine backfires, which means that there are no power valves to blow out, and the rods can be changed in seconds without carburetor removal or fuel draining. Secondly, the carburetor has the unique ability to "hold a tune", so once it is tuned, the carburetor stay's tuned. What this means to you is that compared to other carburetors, the performance remains consistent and the calibration stays unchanged. The lightweight all-aluminum body features a two-piece body that is iridited and assembled with PTFE-coated shafts and pump arm for maximum protection. The simple tub-type bowls and rear-pivot floats all contribute to a carburetor that's reliable, user-friendly and is easily tunable for trouble-free operation.
The Edelbrock 1409 Marine Series 600 CFM electric choke carburetor is a precisely tuned, quality-built carburetor that can handle the harsh abuse only a marine environment can inflict. Several characteristics make the 1409 Marine Series 600 CFM electric choke carburetor an outstanding marine performer. The first one is that metering rods are utilized to transition between circuits. The carburetor is unaffected by engine backfires, which means that there are no power valves to blow out, and the rods can be changed in seconds without carburetor removal or fuel draining. Secondly, the carburetor has the unique ability to "hold a tune", so once it is tuned, the carburetor stay's tuned. What this means to you is that compared to other carburetors, the performance remains consistent and the calibration stays unchanged. The lightweight all-aluminum body features a two-piece body that is iridited and assembled with PTFE-coated shafts and pump arm for maximum protection. The simple tub-type bowls and rear-pivot floats all contribute to a carburetor that's reliable, user-friendly and is easily tunable for trouble-free operation.
| Attributes | |
| ASIN | B00062YA80 |
| Barrel | Four |
| Barrel Quantity | 4 Barrel, 4 Barrel, 4 Barrel |
| Body Height | 3.25 |
| Booster Type | Annular, Annular, annular |
| Bore Diameter | Primary Bore 1.44; Secondary Bore 1.69, Primary Bore 1.44; Secondary Bore 1.69, Primary Bore 1.44; Secondary Bore 1.69 |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| CFM | 600 |
| Choke | Electrical |
| Choke Type | Electric |
| Condition | New, New |
| Country of Origin (Primary) | US |
| EGR Port | No |
| Emission | Without EGR |
| Emission Code | Not in CA |
| Finish | Zinc-Dichromate, Zinc-Dichromate |
| Flange | Square Bore |
| Flange Shape | Square, Square, Square |
| Gasket Or Seal Included | Yes, Yes, Yes |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Main Venturi Diameter | 1.19 |
| Material | Aluminum |
| Maximum Flow Rating | 600, 600, 600 |
| Metering Rod Size | .068 x .047, .068 x .047 |
| NAFTA Preference Criterion Code | B |
| Potential Risk Chemical | Zinc |
| Primary Jet Diameter | 0.098 |
| Primary Power Valve | N/A |
| RGL | WARNING: This product can expose you to Zinc, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Zinc, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| SDR Required Flag | N |
| SDS Sheet Number | NA |
| Secondary Jet Diameter | 0.101 |
| Series | Marine, Marine |
| Spring Force | 5" Hg (Orange) |
| Type | Marine |
| Usage | Marine |
| Warranty Time | 3 |
| GTIN | 00085347014095 |
