265-400 SBC, Tube Size 1.625", Collector Size 2.5"
FLOWTECH Block Hugger headers are ideal for limited space applications where fit and finish is really important. Block Huggers make performance and style easy for engine swaps, and with our new Hugger Toobs you can hook up to an existing exhaust system with ease.
- Computer-controlled mandrel-bent tubing for smooth exhaust flow
- Sturdy 16 gauge tubing
- Tight-tuck design for narrow frame rails
- Easy installation - can be used with stock motor mounts
- Precision die-cut exhaust port flanges
- Engineered and tested for a leak-proof seal
- All necessary hardware included for a complete installation
Information:
Breaking in an engine with ceramic coated headers WILL result in damage to the coating and will VOID all warranties. Ceramic coated headers require several heat cycles to fully cure before they will withstand extreme heat. Flowtech recommends using cast iron exhaust manifolds or old headers to break in new engines to avoid coating damage. Please call Flowtech tech services at 270-781-9741 for additional information regarding ceramic exhaust products. The use of header wraps can cause the header tubes to crack or rust due to excessive heat and moisture build-up. Flowtech does not recommend the use of header wraps as this will void the warranty.
Application Summary:
| Year |
Make/Model |
| FLOWTECH |
Block Hugger headers are ideal |
| Attributes |
| Air Injection Tubes |
No |
| Application |
Automotive |
| ASIN |
B000CMEVJW |
| Bolt size |
3/8-16 x 3/4, 3/8-16 x 3/4 |
| Bolts Included |
Yes |
| Brand |
Flowtech Exhaust, Flowtech Exhaust |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| CARB (California) Compliant |
No, Not Applicable |
| Category |
Exhaust, Exhaust |
| Clearance Category |
Exhaust |
| Coated Finish |
Metallic Ceramic |
| Coating/Finish |
Metallic Ceramic |
| Collector Attachment |
3-Bolt Flange, 3-Bolt Flange |
| Collector Diameter |
2.500 in., 2.50 inch |
| Collector Diameter (in.) |
2.50, 3.50 |
| Collector Reducer Included |
Yes, Yes |
| Collector Reducer Outlet Diameter |
2.50, 2.50 |
| Collector Tube Size |
2.500 in. |
| Collector Tube Size (in.) |
2.5 |
| Color |
Silver, Silver |
| Country of Origin (Primary) |
CN |
| Cylinder Head Flange Thickness |
5/16" |
| Design |
Block Hugger, Block Hugger |
| Discount Percentage |
26-50% |
| Drive |
2WD, 2WD |
| EGT (Exhaust Gas Temperature) Port |
No |
| Emission Code |
4, 4, Off Road |
| Engine |
Chevrolet Small Block Gen I, Chevrolet Small Block Gen I |
| Engine Make/Size |
Chevy Small Block (262-400) |
| Finish |
Silver Metallic Ceramic, Ceramic Coated |
| FLANGE Thickness |
5/16", 0.3125 |
| Gasket Or Seal Included |
Yes |
| Grade Type |
Performance, Performance |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Head Style |
Block Hugger |
| Header Finish |
Silver Ceramic, Silver Ceramic |
| Header Series |
Flowtech |
| Header Style |
Block Hugger, Block Hugger |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
1-5/8, 1.625 |
| Material |
Stainless Steel, Mild Steel |
| Mounting Hardware Included |
Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Oxygen Sensor Port |
No, No |
| part type |
Exhaust Header, Exhaust Header |
| Pipe Wall Gauge |
16 |
| Port Shape |
Round, Oval |
| Primary Tube Dia. |
1-5/8 inch, 1-5/8 inch |
| Primary Tube Diameter |
1.625 in., 1.875 in. |
| Primary Tubing Diameter |
1-5/8, 1-5/8 |
| Product Type |
Headers, Headers |
| Quantity |
Sold as a pair, Sold as a pair |
| Sale Category |
Exhaust |
| SDR Required Flag |
N |
| Sub Category |
Exhaust Manifolds, Exhaust Manifolds |
| Tube Diameter |
1.625 in. |
| Tube Direction |
Down Swept |
| Tube Material |
Mild Steel, Mild Steel |
| Tube Size |
1.625 |
| Tube Wall Thickness |
16, 16 |
| Tube Wall Thickness (GA) |
16GA |
| Warning |
California Proposition 65, California Proposition 65 |
| Warranty Time |
90 |
| GTIN |
00787480310002 |
