A staple in the drag race community, features a built-in 2 step rev control and its famous high output spark energy.
Visually, you'll notice the two terminal strips that allow for easier wiring in your race car. The LED over the power connections will come in handy for troubleshooting as it flashes only when the coil fires. That way you know that the coil, the trigger source and ignition are all functioning properly. The mounting pattern is the same as the 7AL-2 and is supplied with vibration mounts and a few rpm modules.
Visually, you'll notice the two terminal strips that allow for easier wiring in your race car. The LED over the power connections will come in handy for troubleshooting as it flashes only when the coil fires. That way you know that the coil, the trigger source and ignition are all functioning properly. The mounting pattern is the same as the 7AL-2 and is supplied with vibration mounts and a few rpm modules.
- 14,000 RPM with 14.4 Volts
- Built-in 2-Step rev control
- Operates on 4, 6 or 8-cylinder engines
- Supplied with 3000, 7000, 8000, 9000 RPM Chips
- Diagnostic Troubleshooting LED
- 12-18 Volts, Negative Ground
- Terminal strips for convenient hookup
- 6 Amps Per 6,000 RPM; 12 Amps at 12,000 RPM
| Attributes | |
| ASIN | B000N8GILY |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Gold |
| Connector Gender | Terminal Strip |
| Connector Quantity | 2 |
| Country of Origin (Primary) | US |
| Current Draw | 12 Amp at 12000 RPM, 6 Amp per 6000 RPM |
| Emission Code | 4, 4, Off Road |
| Features | Rev Limiter, Rev Limiter |
| Grade Type | Race, Race |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Hazardous Material Code | N |
| Height | 5.75, 5.75 |
| Ignition Type | Performance, Performance |
| Length | 8.25, 8.25 |
| Life Cycle Status Code | Available to Order |
| Maximum RPM | 14,000 |
| Mount Type | Surface Mount, Surface Mount |
| Mounting Hardware Included | Yes, Yes |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Control Module |
| Primary Voltage | 570, 570 Volts |
| Product Type | Ignition, Ignition Box |
| RPM | 14000 |
| RPM Range | 14,000 RPM with 14.4 Volts |
| Sale Category | Tuners and Programmers |
| SDR Required Flag | N |
| Secondary Voltage | 47000, 47,000 Volts |
| Series | Ignition Accessories |
| Spark Duration | 20 Degree Crankshaft Rotation |
| Spark Energy | 160 mJ per spark, 160 mJ/spark |
| Spark Energy (mJ per spark) | 160 |
| Sub Category | Control Modules, Control Modules |
| Subcategory | Ignition Boxes |
| Terminal Gender | Terminal Strip, Terminal Strip |
| Terminal Quantity | 10, 10 |
| Voltage | 12-18 V; Negative Ground |
| Voltage Required | 12-18 Volts, Negative Ground, 12-18 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight and Size | 4.85 lbs.,8.25"L x 3.75"W x 5.75"H, 4.85 lbs., 8.25L x 3.75W x 5.75H |
| Width | 3.75, 3.75 |
| GTIN | 00085132072224 |
