PERTRONIX FLAME-THROWER COIL. 40,000-VOLT RATED WITH 1.5-OHMS OF RESISTANCE. CHROME OIL FILLED CANISTER STYLE.
The Flame Thrower canister coil is designed to mate with the Ignitor Electronic Conversion Kit, but can benefit virtually any distributor type inductive systems. Higher voltage allows larger spark plug gap for added power, smoother response, and improved fuel economy.
The Flame Thrower canister coil is designed to mate with the Ignitor Electronic Conversion Kit, but can benefit virtually any distributor type inductive systems. Higher voltage allows larger spark plug gap for added power, smoother response, and improved fuel economy.
- 40,000 volts.
- Available chrome plated or black for that "stock look".
- For use with inductive ignition systems.
- 1.5 or 3.0 Ohm primary resistance values available.
- Legal in all 50 states and Canada. (C.A.R.B. E.O. #D-57-21)
Information:
The Flame-Thrower canister style coil has been engineered to complement our Ignitor Electronic Ignition Conversion Kits and Plug n’ Play Distributors. Choose from the Flame-Thrower, Flame-Thrower II, and the Flame-Thrower III depending upon system voltage and resistance. Oil filled coils offer great heat control for street driven vehicles, while epoxy filled coils provide superior winding support for high vibration environments in off-road vehicles and boats.| Attributes | |
| ASIN | B00199F2XG |
| Attribute Data | 1 |
| Ballast Resistor Included | No |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Coil Internal Construction | Oil-Filled |
| Coil Shape | Round |
| Coil Wire Attachment | Female/Socket |
| Coil Wire Included | No |
| Color | Chrome |
| Country of Origin (Primary) | CN |
| Emission Code | Legal US |
| Emission Description | This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the appropriate vehicle per the Manufacturer’s Application Guide and Installation Instructions. |
| EmissionFullDES | 1 - This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the Specified vehicle per the Manufacturer’s Current Application Guide, the CARB EO, and Installation Instructions., 1 - This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the Specified vehicle per the Manufacturer’s Current Application Guide, the CARB EO, and Installation Instructions. |
| Finish | Polished, Chrome |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Maximum Diameter | 2.15 |
| Maximum Voltage | 40000, 40,000 V |
| Mount Type | Circular Bracket |
| Mounting Bracket Included | No |
| Mounting Hardware Included | No |
| Mounting Position | Vertical |
| NAFTA Preference Criterion Code | B |
| Overall Height | 6 |
| Primary Inductance | 6.4 |
| Primary Resistance | 1.5 |
| Requires External Resistor | No |
| SDR Required Flag | N |
| Secondary Resistance | 9000 |
| Title (Custom) | PerTronix 40001 Flame-Thrower Coil 40,000 Volt 1.5 ohm Chrome |
| Turns Ratio | 100:1 |
| Voltage | 12, 12V |
| Warranty Time | 90 |
| GTIN | 00694342004859 |
